Benchtop Conductivity/DO Meter YR06384

Description

The Benchtop Conductivity/DO Meter YR06384 is a sophisticated device crafted for accurate measurements in lab and industrial settings. Featuring a 7-inch colored capacitive touch screen, this meter ensures high-resolution and sensitive operations. Its smart microprocessor chip automates tasks like calibration and temperature compensation, increasing user efficiency. The YR06384 stores up to 1000 sets of test data, which can be seamlessly transferred via USB or Bluetooth for convenient analysis, making it a versatile tool across various industries.

Market Price

The Benchtop Conductivity/DO Meter YR06384 is competitively priced for high-precision instruments with similar features. This reflects the technological innovation and extensive capabilities it provides for precision and reliable conductivity and DO measurements. For a personalized quote, we invite you to request an estimate through our Kalstein Plus platform.

Frequently Asked Questions

What is the calibration process for the YR06384? The YR06384 features an automatic calibration process ensuring precision and reducing maintenance effort.

Can the data be transferred to a computer? Yes, data can be easily transferred via USB or Bluetooth for flexible and convenient data management.

Advantages and Disadvantages

Advantages:

High-resolution touch screen for easy navigation.
Automatic calibration and compensation for streamlined operations.
Versatile measurement modes suitable for various applications.
Effortless wireless data transfer via Bluetooth.
Large data storage capacity for enhanced utility.

Disadvantages:

Initial investment is higher compared to basic meters.
Regular calibration needed for optimal performance.

Field Use

The Benchtop Conductivity/DO Meter YR06384 is designed for use in water quality analysis, environmental monitoring, and industrial applications. Its ability to measure conductivity, TDS, and DO makes it essential for researchers and field technicians. The robust construction and fast response times ensure consistent reliability across different environments.

Recommendations

For peak performance of the YR06384, regular calibration with suitable standards is recommended. Proper cleaning and maintenance of electrodes after each use will extend the device’s lifespan. Keeping the firmware updated with manufacturer-provided enhancements will ensure optimal functionality.

Features

7-inch colored capacitive touch screen.
Intelligent microprocessor with automated functions.
Bluetooth and USB data transfer capabilities.
Smart electrode status display for improved accuracy.
Data storage capacity of 1000 sets.

Technical Specifications

Model		YR06384
Cond.	Measuring range	Conductivity:
		(0.00~20.00)μS/cm, (20.0~200.0)μS/cm
		(200~2000)μS/cm, (2.00~20.00)mS/cm
		(20.0~200.0)mS/cm,
		(200~2000)mS/cm (K=10)
		TDS:(0 ~ 100)g/L
		Salinity:(0 ~ 100)ppt
		Resistivity:(0 ~ 100)MΩ·cm
	Resolution	0.01/0.1/1μS/cm; 0.01/0.1mS/cm
	Accuracy	Electrode: ±0.5% FS, Meter: ±0.8% FS
	Temp. compensation range	(0 ~ 50)ºC, auto
	Electrode constant	0.1/0.5/1/5/10/50/100 cm-1
	Reference Temp.	25ºC,20ºC,18ºC
DO	Measuring range	(0 ~ 20.00)mg/L(ppm) (0 ~ 200.0)%
	Resolution	0.1/0.01 mg/L(ppm) 1/0.1 %
	Accuracy	Electrode: ±0.10 mg/L, Meter: ±0.40 mg/L
	Response time	≤30s (25ºC, 90%response)
	Residual current	≤0.1 mg/L
	Temp compensation	(0 ~ 45)ºC, auto
	Salinity compensation	(0 ~ 45) ppt, auto
	Pressure compensation	(80 ~ 105) kPa, auto
	Auto calibration	Air saturated by water; water saturated by air
	Electrode type	Polarographic
Temp.	Range	(-10 ~ 110)ºC
	Resolution	0.1ºC
	Accuracy	5 ~ 60ºC:±0.4ºC Others: ±0.8ºC
Other	Display	7-inch colored capacitive touch screen
	Data storage	1000 sets
	Power	12V/1A
	Output	USB, RS232, Bluetooth
	Ambient Temp.	15 ~ 30 ºC
	Ambient Humidity	≤85%
	IP grade	IP54
	Dimensions/N.W.	240×170×70mm/600g
	Shipping Size/G.W.	470x430x85mm/2.6kg

Additional information

Weight	3 kg
Dimensions	47 × 43 × 8 cm
