Description
The Doppler Fetal Monitor YR02180 is a state-of-the-art medical device designed to provide comprehensive patient monitoring, particularly in high-demand environments such as operating theatres (OT) and intensive care units (ICU). Equipped with a 17-inch LCD screen and featuring a semi-modular configuration, this versatile monitor offers six standard parameters: ECG, SpO2, TEMP, NIBP, RESP, and PR/HR. Users can further customize their setup with optional features like a touch screen, additional ECG leads, and diverse mounting solutions, ensuring applicability across varied clinical needs.
Market Price
The market positioning of the Doppler Fetal Monitor YR02180 reflects its advanced capabilities and robust design. Although specific pricing may vary based on configuration and additional features, this competitive range confirms the device as a smart investment for healthcare facilities aiming to elevate patient care services.
Frequently Asked Questions
What are the standard parameters included with the monitor? This monitor provides six essential parameters: ECG, SpO2, TEMP, NIBP, RESP, and PR/HR.
Can the monitor be configured for different clinical settings? Absolutely, it offers flexibility with optional features such as a touch screen and extended ECG leads, adaptable to diverse environments.
Advantages and Disadvantages
Advantages: The adaptability of the Doppler Fetal Monitor YR02180 is one of its key advantages. Its customizable features make it suitable for various patient monitoring scenarios, ensuring comprehensive data capture.
Disadvantages: Setup can be technically demanding initially, and investing in additional features may result in extra costs.
Field Use
The Doppler Fetal Monitor YR02180 excels in critical care settings such as ICUs, offering reliable and continuous patient monitoring. Its semi-modular design allows seamless adaptation to the changing needs of healthcare professionals.
Recommendations
To ensure the Doppler Fetal Monitor YR02180 operates at its best, it is advisable to follow regular calibration and maintenance as per the manufacturer’s specifications. Healthcare staff should participate in training sessions to fully exploit the monitor’s capabilities. For immediate inquiries or to customize your order, request a quote via our Kalstein Plus platform.
Features
- 17-inch LCD screen with semi-modular configuration
- Standard parameters: ECG, SpO2, TEMP, NIBP, RESP, PR/HR
- Optional features: Touch screen, extended ECG leads, mounting solutions
- Designed for use in OT and ICU environments
Technical Specifications
| Model | YR02180 | |
|
ECG
|
Lead mode | 5 Leads(RA,LA,LL,RL,V) |
| Connection method | I, II, III,AVR,AVL,AVF,V | |
| Lead Mode | 3 Leads (RA,LA,LL) | |
| Connection method | I, II,III | |
| Gain | x250, x500, x1000, x2000 | |
| Accuracy | ±5% | |
| Resolution | 1bpm | |
| Sensitivity | >200(uVp-p) | |
| Differential input impedance | ≥5MΩ | |
| ST segment Monitoring Range | ||
| Measure Range | -1.0~+1.0mV | |
| Measure Accuracy | -0.8mV~+0.8mV | |
|
Heart Rate
|
Measuring range | 40~240bpm |
| Accuracy | ±3bpm | |
| Resolution | 1bpm | |
| Sensitivity | >200UVp-p | |
|
Respiration
|
Method | Impedance between R-F(RA-LL) |
| Measuring Impedance Range | 0.3~3.0 MΩ | |
| Bandwidth | 0.1~2.5Hz | |
| Respiration Rate | Adult: 7~120BrPM | |
| Neo/Ped | 7~150BrPM | |
| Resolution | 1 BrPM | |
| Accuracy | ±2 BrPM | |
|
NIBP
|
Method | Oscillometric |
| Measuring Interval in AUTO Mode | 1,2,3,4,5,10,15,30,60,90,120,180,240(Min) | |
| Measuring Period in STAT Mode | 5 Min | |
| Pulse Rate Range | 40~240bpm / 40~150bpm | |
| Alarm Type | SYS, DIA, MEAN | |
| Resolution | ||
| Pressure | 1mmHg | |
|
SPO2
|
Display | Number of SPO2,waveform of capacity,Pulse |
| Measuring range | 0~100% | |
| Resolution | 1% | |
| Accuracy | 70~99% (±2%) | |
| Pulse rate range | 0~300bpm | |
|
TEMP
|
Channel | 2 |
| Measuring and Alarm Range | 0~50ºC | |
| Resolution | 0.1ºC | |
| Accuracy | 0.1ºC | |
| Actualization interval | about 1 Second. | |
| Average Time Constant | <10 Second. | |
