Description
The High Capacity Series for Storage or Transport (Round Canisters) YR05393 // YR05402 is innovatively designed to enhance the efficiency and safety of biological sample storage and transport. Constructed from strong yet lightweight aluminum, these canisters ensure durability and secure handling of sensitive materials. Featuring a heavy-duty lockable enclosure and numbered index location points, they offer excellent security and ease of organization. Additionally, these canisters boast high thermal efficiency, ultra-low evaporation loss, and a robust five-year vacuum warranty, making them a cost-effective choice with extended hold times. Optimized for straw storage, the series offers optional LN₂ dispense pumps and roller bases, enhancing usability and mobility.
Market Price
The price of these High Capacity Series canisters varies depending on specific features and capacity chosen. Generally, similar high-quality storage canisters in the market range over a wide spectrum, reflecting their durability and efficiency. For detailed pricing and to explore our latest offers, we recommend requesting a quote through our Kalstein Plus platform. There, customers can benefit from automated quotes customized to their unique requirements.
Frequently Asked Questions
What is the maximum storage capacity of these canisters? These canisters can store up to approximately 2832 straws (0.25ml each), varying by model and layers.
Are the canisters easy to transport? Yes, designed to be lightweight with optional roller bases for easier mobility, they’re highly transport-friendly.
How do I ensure the security of my samples? Equipped with a heavy-duty lockable enclosure, these canisters provide the utmost security during both storage and transport.
Advantages and Disadvantages
The primary advantages include high thermal efficiency and ultra-low evaporation loss, ensuring prolonged storage times, complemented by a secure, lockable enclosure. Their lightweight aluminum construction facilitates easy handling. However, the initial investment cost might be considered a disadvantage, though it offers long-term durability and reliability.
Use in the Field
These canisters are ideal for laboratories and medical facilities needing efficient and secure biological sample storage. Their high capacity suits large-scale operations prioritizing space efficiency and sample safety. The narrow neck design reduces evaporation loss, and the optional roller bases enhance mobility, essential in dynamic work environments.
Recommendations
To optimize canister performance and longevity, regular checks on the lockable mechanism and routine vacuum insulation maintenance are recommended. Utilizing the roller base during transport minimizes the risk of physical damage.
Features
- Strong and lightweight aluminum construction
- Heavy-duty lockable enclosure for security
- Numbered index location points for organization
- Straw storage compatibility
- High thermal efficiency with ultra-low evaporation loss
- Five-year vacuum warranty
- Available options for LN₂ dispense pump and roller bases
- Extended hold time and high capacity
Technical Specifications
| Model | YR05393 | YR05394 | YR05395 | YR05396 | YR05397 | |
| Maximum Capacity | No. of Canisters | 6（0） | ||||
| No. of Straws (Single Layer, 0.5ml each) | — | 792 | ||||
| No. of Straws (Single Layer, 0.25ml each) | — | 1788 | ||||
| No. of Straws (Double Layer, 0.5ml each) | 1284 | — | 1284 | |||
| No. of Straws (Double Layer, 0.25ml each) | 2832 | — | 2832 | |||
| Performance | Volume of LN2 (L) | 13 | 15 | 20 | ||
| Static Evaporation* (L/Day) | 0.12 | 0.11 | 0.12 | |||
| Static Holding Time** (Day) | 109 | 134 | 168 | |||
| Dimensions | Opening Diameter (mm) | 50 | 50 | 50 | ||
| Height (mm) | 623 | 591 | 672 | |||
| Outside Diameter (mm) | 310 | 394 | 394 | |||
| Canister Outside Diameter (mm) | 38 | 38 | 38 | |||
| Outside Height(mm) | 276 | 120 | 120/276 | |||
| Empty Weight (kg) | 6.3 | 8.5 | 9.5 | |||
| Full Weight (kg) | 17.3 | 20.5 | 28.1 | |||
| Shipping Weight (kg) | 11 | 13 | 15 | |||
| Additional Features | Includes 6 canisters (height 276mm), lockable cap, and protective jacket | Includes protective jacket only | Includes 6 canisters (height 120mm), lockable cap, and protective jacket | Includes protective jacket only | Includes 6 canisters (height 276mm), lockable cap, and protective jacket | |
| Model | YR05398 | YR05399 | YR05400 | YR05401 | YR05402 | |
| Maximum Capacity | No. of Canisters | 6（0） | ||||
| No. of Straws (Single Layer, 0.5ml each) | 792 | |||||
| No. of Straws (Single Layer, 0.25ml each) | 1788 | |||||
| No. of Straws (Double Layer, 0.5ml each) | 1284 | |||||
| No. of Straws (Double Layer, 0.25ml each) | 2832 | |||||
| Performance | Volume of LN2 (L) | 20 | 30 | |||
| Static Evaporation* (L/Day) | 0.12 | |||||
| Static Holding Time** (Day) | 168 | 254 | ||||
| Dimensions | Opening Diameter (mm) | 50 | ||||
| Height (mm) | 672 | 705 | ||||
| Outside Diameter (mm) | 394 | 462 | ||||
| Canister Outside Diameter (mm) | 38 | |||||
| Outside Height(mm) | 120/276 | |||||
| Empty Weight (kg) | 9.5 | 12.9 | ||||
| Full Weight (kg) | 28.1 | 36.6 | ||||
| Shipping Weight (kg) | 15 | 18 | ||||
| Additional Features | Includes 6 canisters (height 276mm), lockable cap, and protective jacket | Includes 6 canisters (height 120mm), lockable cap, and protective jacket | Includes protective jacket only | Includes 6 canisters (height 276mm), lockable cap, protective jacket, roller base is optional | Includes 6 canisters (height 120mm), lockable cap, and protective jacket, roller base is optional | |
