Description
The Portable Conductivity/DO Meter YR06382 is a versatile and reliable instrument designed for accurate measurements of conductivity and dissolved oxygen (DO). This advanced device is equipped with an intelligent microprocessor chip, offering features such as auto calibration, automatic temperature compensation (ATC), data storage, and auto diagnosis. Its large LCD screen with controllable white backlight ensures easy readability in any environment, making it the perfect choice for professionals requiring precision across diverse settings.
Market Price
In the realm of professional-grade meters, the price of portable conductivity/DO meters varies based on their features and specifications. The YR06382 is competitively positioned within this range, offering significant value through its advanced technology and comprehensive functionality. Experience this quality personally by requesting a quote through Kalstein Plus and take a step towards superior water quality analysis.
Frequently Asked Questions
Q: How long does the electrode take to polarize?
A: The polarographic DO electrode polarizes in approximately 3-5 minutes, ensuring quick and efficient measurement readiness.
Q: What type of batteries does the meter require?
A: The YR06382 operates with two AA batteries, providing simple replacement options and sustained power.
Q: Is this meter suitable for outdoor use?
A: Yes, the IP57 rating guarantees that the device is both dustproof and waterproof, making it ideal for outdoor applications.
Advantages and Disadvantages
Advantages: The YR06382 stands out with its high accuracy and adaptable measurement capabilities, making it ideal for various applications. Its durable design, user-friendly LCD, and substantial data storage enhance user experience.
Disadvantages: Users might encounter a learning curve due to the meter’s extensive capabilities. Manual pressure compensation in DO mode may require additional configuration time.
Field Use
Ideally suited for monitoring water quality across diverse environments—ranging from environmental testing to aquaculture and laboratory research—the YR06382 offers precision and portability for trustworthy results. Whether analyzing conductivity in rivers or DO levels in fish farms, this portable meter provides the accuracy needed for professional-grade analysis.
Recommendations
For optimal performance, regularly maintain and calibrate the electrodes. Storing the device in a clean, dry location can prolong its lifespan. Utilize the data storage capacity to track historical data trends, providing a comprehensive overview of water quality changes over time.
Features
- Large LCD screen with controllable backlight
- Intelligent functions including auto calibration and ATC
- Advanced conductivity measurement technology
- Multiple measurement modes: conductivity, TDS, salinity, resistivity
- Polarographic DO electrode with short polarization time
- IP57 dustproof and waterproof rating
- Compact size with 200 data set storage capacity
Technical Specifications
| Model | YR06382 | |
|
Cond.
|
Measuring range
|
Conductivity: |
| (0.00~19.99)μS/cm | ||
| (20.0~199.9)μS/cm | ||
| (200~1999)S/cm | ||
| (2.00~19.99)mS/cm | ||
| (20.0~199.9)mS/cm | ||
| TDS:(0~100)g/L | ||
| Salinity:(0~100)ppt | ||
| Resistivity:(0~100)MΩ·cm | ||
| Resolution | 0.01/0.1/1μS/cm; 0.01/0.1 mS/cm | |
| Accuracy | ±1.0% FS, Overall:±1.5% FS | |
| Temp. compensation | (0~100)ºC(Auto/manual) | |
| Electrode constant | 0.1 / 1 / 10 cm-1 | |
|
DO
|
Measuring range | (0 ~ 20.00) mg/L(ppm), (0 ~ 200.0)% |
| Resolution | 0.1/0.01 mg/L(ppm), 1/0.1 % | |
| Accuracy | Electrode: ±0.10 mg/L, Instrument: ±0.40 mg/L | |
| Response time | ≤30s (25ºC, 90%response) | |
| Residual current | ≤0.1 mg/L | |
| Temp. compensation | (0 ~ 45)ºC (auto) | |
| Salinity compensation | (0 ~ 45) ppt (auto) | |
| Pressure compensation | (66 ~ 200) kPa (manual) | |
| Auto calibration | Air saturated by water, water saturated by air | |
| Electrode type | Polarographic | |
|
Temp.
|
Measuring range | (0 ~ 100)ºC |
| Resolution | 0.1ºC | |
| Accuracy | 5 ~ 60ºC:±0.4ºC Others: ±0.8ºC | |
|
Other
|
Data storage | 200 sets |
| Power | Two AA batteries (1.5V x2) | |
| Ambient Temp. | 5 ~ 35 ºC | |
| Ambient humidity | ≤85% | |
| IP grade | IP57 Dustproof and waterproof | |
| Dimensions/N.W. | (65×120×31)mm/180g | |
| Shipping size/G.W. | (460×300×55)mm/1Kg | |
